1. Discharge pressure: 550 CFM
2. Displacement: 15 bar
3. Power: 190HP Diesel engine
I. Application
Portable Screw Air Compressors (Diesel power series) are widely used in various industries for roads, railways, mines, water conservation and supplies, shipbuilding, city development, energy development, military services, and others.
Screw Air Compressors (Diesel power series) are highly efficient and reliable with a full range of selections. The power range is 132 kW to 565 kW, the displacement covers up to 43 m3/min, and the discharge pressure amounts up to 3.5 MPa.
II. Technical Parameter
Model | LG 15/15 |
Gas displacement m3/min | 15-17 |
Rated discharge pressure Mpa | 1.2-1.5 |
Weight kg | 2200 |
L×W×H mm | 3020×1520×2180 |
Tyre ×Qty | 185/80R14 95S×4 |
Engine Brand | Yuchai |
Model | YC6J190-H300 |
Type | Vertical、Inline、Water cooled |
Air Intake Type | Supercharge |
Cylinder diameter×stroke×numbers | 105×125×6 |
Displacement L | 6.494 |
Rated rotation speed r/min | 1800 |
Unloading speed r/min | 1400 |
Rated power kW（HP） | 140（190） |
Engine oil capacity L | 15 |
Fuel capacity L | 256 |
Electrical system voltage V | 24 |
